EXPERIENCE THE POWER OF MUSIC
Exceptional mechanical design and brilliant acoustic engineering have created the new revamped Signature Series 3 marine subwoofers, which deliver premium low frequencies for a truly memorable audio entertainment experience.
- Experience industry-first marine subwoofers with CRGBW LED lighting1.
- The new Signature Series 3 subwoofers now pack an enhanced 600 watts of peak power.
- Enjoy high-resolution bass reproduction from the quality polypropylene cone.
- With an increase in real power, the voice coil provides a sound exclusive to the Signature Series 3.
- The subwoofers are available in 10-inch designs with both classic and sports style grilles.
- Engineered to last season after season, the subwoofers include a supported 3-year warranty.
DESIGNED AND ENGINEERED TO TRUE-MARINE™ STANDARDS
Built on the True-Marine design philosophy from Fusion®, the Signature Series 3 subwoofers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog, temperature, vibration and UV.
DESIGNED TO COMPLY WITH ISO 12216
Tested to international standards for pressure and watertightness, the Signature Series 3 subwoofers are designed and built to the highest industry standards for quality and robustness.
THE FINEST MATERIALS AND ACOUSTIC ENGINEERING
The Signature Series 3 subwoofers incorporate premium materials and marine-specific design elements. This communicates not only their premium aesthetics but also their ability to reproduce high-quality audio while out on the water.
POLYPROPYLENE CONE TECHNOLOGY
Defined, high-resolution low-frequency acoustics are a result of the excellent self-damping and bass reproduction from the quality polypropylene cone.
LARGE-DIAMETER VOICE COIL
Delivering an increase in real power and efficiency, the large-diameter voice coil provides a signature sound with wave-rippling bass exclusive to the Signature Series 3 subwoofers.
HIGH-GRADE BASKET CONSTRUCTION
The basket is constructed using high-grade engineered plastics to deliver unprecedented durability when exposed to the marine environment.
PREMIUM CRGBW LED LIGHTING
Industry-first marine subwoofers with CRGBW (cool white, red, green, blue, warm white) illuminate an unprecedented spectrum of colours from premium pastels to vibrant hues to enhance your audio entertainment experience.
CONTROLLING THE CRGBW LIGHTING
Control the colour (static or dynamic), brightness, light mode and speed by using the optional MS-CRGBWRC wireless remote control (sold separately) or from a Garmin multifunction display via OneHelm™ integrated digital switching (lighting partner controller required).
GENERAL SPECIFICATIONS
| Physical dimensions (Diameter x Depth) | Classic Subwoofer: 10.83" x 6.38" (275 x 162 mm) Sports Subwoofer: 10.83" x 6.77" (275 x 172 mm) |
|---|---|
| Water and Dust Rating | IP65 |
| Speaker size | 10" |
| Peak power (Watts) | 600 W |
| RMS power (Watts) | 300 W |
| Sensitivity (1 W/1 m) | 86 dB |
| Magnetic structure | 68 oz |
| Frequency response | 30 Hz-2 kHz |
| Nominal impedance | 4 ohms |
| Recommended amplifier power (RMS) | 50-600 W |
| LED lighting | Yes - CRGBW (sports-style only) |
| LED supply voltage | 10.8-16 VDC (sports-style only) |
| LED load current @ 14.4 VDC | 300 mA (sports-style only) |
| Operating temperature range | 32° to 122° F (0° to 50° C) |
| Voice coil diameter | 2" |
| Cone material | Polypropylene cone with rubber surround |
| Compass-safe distance | 205" (520 cm) |
| Warranty | 3 years |
MOUNTING DIMENSIONS
| Mounting diameter clearance | 8.78" (223 mm) |
|---|---|
| Mounting depth clearance | 5.24" (133 mm) |
OPTIMUM ENCLOSURE RECOMMENDATIONS
| Sealed enclosure volume (fully filled with absorption material) | 0.6 cubic ft (17.2 L) |
|---|---|
| Ported (vented) enclosure volume (lined with absorption material) | 1.6 cubic ft (45 L) |
| Port diameter | 4" (104 mm) |
| Port length | 10.43" (265 mm) |
Box Includes
- One subwoofer
- Documentation
